VK-1000 Power Board Rev. 2A
256 6 Apr 15.2025, 04:01:01
Moderate size (13x17.5cm) AC and DC power control and high-voltage (4KV) generator board. PCB GoGo produced the boards then purchased the small SMT components and mounted them. I purchased and will install the large thru-hole parts including the high-voltage transformer. Communication was good and the single small problem (my mistake in the BOM) was identified early by PCB GoGo and fixed with just a one-day delay. The 50 completed boards were very well packed (individual custom-size zip-lock anti-static bag), wrapped in groups of 10 with anti-static bubble pack separating each board then surrounding each pack. The 5 packs were placed in a double-wall box with sheets of 1" thick polyethylene foam on all 6 sides. Would have survived a direct drop from a plane! forum forum forum forum
