Automotive ADAS (Advanced Driver Assistance Systems) operate in extremely harsh environments—ranging from –40°C to 125°C temperature cycling and 10–2000Hz vibration. The reliability of ADAS HDI (High-Density Interconnect) substrates used in camera modules, radar, and millimeter-wave units has a direct impact on driving safety.

Industry data shows that non-reinforced ADAS HDI boards experience over 25% cracking after 3000 thermal cycles, and one OEM even recalled 12,000 vehicles after low-temperature cracking caused lane-keeping failure.
With 6 years of experience in automotive ADAS HDI manufacturing, PCBGOGO delivers HDI boards fully certified to AEC-Q200, achieving over 5000 thermal cycles without cracking.

This article breaks down the core failure risks, reinforcement strategies, and verification standards to help OEMs and Tier-1 suppliers prevent ADAS reliability failures.

Why ADAS HDI Substrates Crack Under Low Temperatures

ADAS HDI substrates must comply with AEC-Q200 Chapter 4, which focuses on temperature, vibration, and moisture resistance. The three major reliability risks are:

Thermal Cycling Risk (–40°C to 125°C)

Standard HDI materials (Tg≈150°C) often lose mechanical strength after repeated cycling. After 3000 cycles, interlayer peel strength can drop from 1.8 N/mm to 0.8 N/mm, below the AEC-Q200 minimum of 1.0 N/mm.

Required material performance:

• Tg ≥ 170°C

• Toughness coefficient ≥ 3.5

• High peel strength retention after thermal fatigue

Vibration Risk (10g, 10–2000Hz)

Blind vias and trace corners are highly vulnerable to cracking under high-frequency vibration common in ADAS module locations.

Automotive-grade design requirements:

• Blind via copper thickness ≥ 20 μm

• Trace corner radius ≥ 0.1 mm

• Must meet IPC-6012 Automotive Addendum

Moisture & Heat Risk (85°C / 85% RH)

Poor dielectric stability can degrade radar signal integrity.
AEC-Q200 Clause 4.7 limits dielectric constant fluctuation to ±0.2, otherwise radar attenuation can increase by over 15%.

Recommended Automotive-Grade Materials

• Shengyi S2116 – Tg 165°C, toughness 3.8, peel strength 1.9 N/mm

• Rogers RO4835 – Tg 280°C, dielectric stability ±0.05 in humid heat

• Solder alloy: SnAg3.0Cu0.5 – Better low-temperature ductility
  All above are validated by PCBGOGO Automotive Material Certification.

Practical Engineering Solutions to Prevent Low-Temperature Cracking

Below is the complete technical solution following automotive-grade requirements: materials → structure → process control.

Step 1: Material Upgrades (Automotive-Grade Requirements)

HDI Base Material

• Shengyi S2116 (Tg165°C) for general ADAS modules

• Rogers RO4835 (Tg280°C) for near-engine compartments

• Thickness tolerance: ±0.03 mm

• Verified under AEC-Q200 Clause 4.2

Solder System

• SnAg3.0Cu0.5 SAC305

• Pad copper thickness: 2 oz

• IMC (Intermetallic compound) thickness: 0.8–1.2 μm (measured via metallographic microscope)

Solder Mask

• High-temperature type (150°C for 1000h without discoloration)

• Must meet IPC-SM-840E Class 3

Step 2: Structural Reinforcement

Blind Via Design

• Via diameter: 0.2 mm

• Copper thickness ≥ 20 μm

• Filling rate ≥ 99% (no voids)

• Verified via X-ray per IPC-A-600G Class 3

Trace Design

• Minimum trace/space: 0.15/0.15 mm

• Corner radius ≥ 0.1 mm

• Power lines ≥ 0.3 mm, copper 2 oz

Edge Reinforcement

For boards in high-vibration zones:

• Add 0.5 mm FR-4 stiffeners bonded with epoxy

• Boosts bending strength by 40% (PCBGOGO test result)

Step 3: Process Control (Crucial for Automotive Yield)

Lamination

• 160°C ±5°C

• 25 kg/cm2

• 80-minute dwell (avoids resin brittleness)

Plating

• Current density: 1.6 A/dm2, 30 minutes

• Ensures via wall copper ≥ 20 μm, thickness variation ≤ ±1 μm

Cleaning

• Ultra-sonic cleaning

• Ion contamination ≤ 1.5 μg/in2 per IPC-TM-650 2.3.28

Reliability Validation (AEC-Q200 Compliance)

PCBGOGO performs full automotive validation:

Thermal Cycling Test

• Conditions: –40°C (30 min) ? 125°C (30 min), 5000 cycles

• Must meet:

• Peel strength ≥ 1.0 N/mm

• Resistance change ≤ 10%

• No cracking / delamination

• Tested using PCBGOGO TH-500 chamber

Vibration Test

• 10–2000Hz sweep, 10g

• XYZ directions, 2h each

• Requirements:

• No blind via fracture

• No trace detachment

• Tested using PCBGOGO VIB-400 vibration table

Moisture & Heat Test

• 85°C / 85% RH for 1000h

• Must meet:

• Dielectric constant fluctuation ≤ ±0.2

• Insulation resistance ≥ 101 MΩ

PCBGOGO’s Automotive ADAS HDI Service System

PCBGOGO provides a full lifecycle automotive-grade HDI assurance:

? Automotive-Grade Material Traceability

Every batch includes AEC-Q200 compliance documentation.

? Reliability Pre-Testing

• Thermal cycling

• Vibration

• High-humidity dielectric stability

? Mass-Production Process Locking

• Parameter deviation ≤ ±2%

• Ensures stable yield during automotive scaling

With these standards, PCBGOGO helps OEMs eliminate ADAS HDI cracking risks and meet global automotive reliability requirements.
